How to build CppRestSDK using Vcpkg in Visual Studio 2019 (X64 windows & X86 windows)

 C++ REST SDK

The C++ REST SDK is developed by Microsoft.

It's a  modern asynchronous C++ API design  for cloud-based client-server communication in native code.

By using this project  C++ developers can connect to and interact with services.

C++ REST SDK can be installed on Windows by using VCPKG

Download C++ Rest SDK GitHub Repo - Microsoft Original Repository

Install packages with VCPKG

Install Visual Studio with C++

Install Windows SDK

git clone https://github.com/microsoft/cpprestsdk.git

Go inside VCPKG folder

.\vcpkg\bootstrap-vcpkg.bat

To use vcpkg with Visual Studio, Run the command below.

.\vcpkg\vcpkg integrate install

Run Following command to install the libraries list zlib ,openssl ,boost-system, boost-date-time ,boost-regex, boost-interprocess, websocketpp, brotli

X64

vcpkg install --triplet x64-windows zlib openssl boost-system boost-date-time boost-regex boost-interprocess websocketpp brotli

X86

vcpkg install --triplet x86-windows zlib openssl boost-system boost-date-time boost-regex boost-interprocess websocketpp brotli

Open cppretsdk in Visual Studio 2019 IDE

Right click on the file explorer window

Open in Visual Studio 2019

Open & Edit CMakeSettings.json file - Add X64 and X86 settings

{

  "configurations": [

    {

      "buildCommandArgs": "",

      "buildRoot": "${projectDir}\\out\\build\\${name}",

      "cmakeCommandArgs": "",

      "cmakeToolchain": "${projectDir}/vcpkg/scripts/buildsystems/vcpkg.cmake",

      "configurationType": "Debug",

      "ctestCommandArgs": "",

      "generator": "Visual Studio 16 2019 Win64",

      "inheritEnvironments": [ "msvc_x64_x64" ],

      "installRoot": "${projectDir}\\out\\install\\${name}",

      "intelliSenseMode": "windows-msvc-x64",

      "name": "x64-Debug (default)",

      "variables": [

        {

          "name": "VCPKG_TARGET_TRIPLET",

          "value": "x64-windows",

          "type": "STRING"

        },

        {

          "name": "Boost_USE_STATIC_LIBS",

          "value": "False",

          "type": "BOOL"

        },

        {

          "name": "CPPREST_FILEIO_IMPL",

          "value": "win32",

          "type": "STRING"

        },

        {

          "name": "_VCPKG_INSTALLED_DIR",

          "value": "${projectDir}/vcpkg/installed",

          "type": "PATH"

        },

        {

          "name": "LIB_EAY_RELEASE",

          "value": "${projectDir}/vcpkg/installed/x64-windows/debug/lib/libcrypto.lib",

          "type": "FILEPATH"

        },

        {

          "name": "OPENSSL_APPLINK_SOURCE",

          "value": "${projectDir}/vcpkg/installed/x64-windows/include/openssl/applink.c",

          "type": "FILEPATH"

        },

        {

          "name": "SSL_EAY_RELEASE",

          "value": "${projectDir}/vcpkg/installed/x64-windows/lib/libssl.lib",

          "type": "FILEPATH"

        },

        {

          "name": "WEBSOCKETPP_DIR",

          "value": "${projectDir}/vcpkg/installed/x64-windows/share/websocketpp",

          "type": "PATH"

        }

      ]

    },

    {

      "buildCommandArgs": "",

      "buildRoot": "${projectDir}\\out\\build\\${name}",

      "cmakeCommandArgs": "",

      "cmakeToolchain": "${projectDir}/vcpkg/scripts/buildsystems/vcpkg.cmake",

      "configurationType": "Debug",

      "ctestCommandArgs": "",

      "generator": "Visual Studio 16 2019",

      "inheritEnvironments": [ "msvc_x86" ],

      "installRoot": "${projectDir}\\out\\install\\${name}",

      "intelliSenseMode": "windows-msvc-x86",

      "name": "x86-Debug",

      "variables": [

        {

          "name": "VCPKG_TARGET_TRIPLET",

          "value": "x86-windows",

          "type": "STRING"

        },

        {

          "name": "Boost_USE_STATIC_LIBS",

          "value": "False",

          "type": "BOOL"

        },

        {

          "name": "CPPREST_FILEIO_IMPL",

          "value": "win32",

          "type": "STRING"

        },

        {

          "name": "_VCPKG_INSTALLED_DIR",

          "value": "${projectDir}/vcpkg/installed",

          "type": "PATH"

        },

        {

          "name": "LIB_EAY_RELEASE",

          "value": "${projectDir}/vcpkg/installed/x86-windows/debug/lib/libcrypto.lib",

          "type": "FILEPATH"

        },

        {

          "name": "OPENSSL_APPLINK_SOURCE",

          "value": "${projectDir}/vcpkg/installed/x86-windows/include/openssl/applink.c",

          "type": "FILEPATH"

        },

        {

          "name": "SSL_EAY_RELEASE",

          "value": "${projectDir}/vcpkg/installed/x86-windows/lib/libssl.lib",

          "type": "FILEPATH"

        },

        {

          "name": "WEBSOCKETPP_DIR",

          "value": "${projectDir}/vcpkg/installed/x86-windows/share/websocketpp",

          "type": "PATH"

        }

      ]

    }

  ]

}

Build cpprestsdk  - X64

Select X64-Debug (default) for build configuration

Select & Right Click on CMakeLists.txt

Select & Click Build

Before Building it for X64 following command should have been executed & packages should have been installed properly

vcpkg install --triplet x64-windows zlib openssl boost-system boost-date-time boost-regex boost-interprocess websocketpp brotli

You can find the built libraries in the below folder

cpprestsdk\out\build\x64-Debug (default)\Release\Binaries\Debug folder

Build cpprestsdk  - X86

Select X86-Debug  for build configuration

Select & Right Click on CMakeLists.txt

Select & Click Build

Before Building it for X86 following command should have been executed & packages should have been installed properly

vcpkg install --triplet x86-windows zlib openssl boost-system boost-date-time boost-regex boost-interprocess websocketpp brotli

You can find the built libraries in the below folder

cpprestsdk\out\build\x86-Debug\Release\Binaries\Debug

Source Code Download

https://github.com/SaralaSewwandi/cpprestsdk
